We have a 10m wide x 6m deep x 5m high trailer stage.
Once the unit is in position on site it takes two people roughly one hour to set up.

The Mobile Stage is a towable trailer stage made to strict German T.U.V. standards in Europe by a leading trailer construction company specialising in aluminium fabrication. The stage is designed and built in accordance with The Institution of Structural Engineers Guidance on Design Procurement and use of Temporary Demountable Structures.

A comprehensive set of Health and Safety documentation is available with our trainer stages, including Certificate of Conformity to all relevant EC directives and DIN requirements. We can provide a comprehensive risk assessment and method statement for use of the mobile stage at your event.

When set up, the weight of the mobile stage is taken by 6 wind-down legs so that the stage is stable and the trailer suspension is by-passed. These legs also level the main stage central section chassis. A further 16 telescopic legs, 8 per side, support the front and rear areas of the stage. Whilst a reasonably level surface location is preferred sloping areas can be easily accommodated, within reason.

The bigger stage requires a minimum of 3m entrance/gate width and entrance-way roof height of 4.2m to enter a site! Please remember that the access must be clear of tree branches, and overhead wires.

Roof:

The stage roof is made of aluminium truss type lattice and has a rugged flame retardant PVC cover and can be used to hang standard lighting clamps, backdrops, sponsors banners etc.

Maximum roof loading is 490Kg. The roof rises on a hydraulic ram. There are 2 triangular truss which additionally support the roof at the front, these can be used to hang stage lights, or banners.

Small light fixtures can be hung from the roof before lifting, additionally six rigging eyes are provided to allow chain hoists to be rigged quickly.

Stage Floor:

The trailer stage floor is made of non-slip resin coated exterior marine ply on an immensely strong aluminium sub frame. Handrails to the rear and sides are standard.

P.A. Wings:

To make the stage space itself as clear as possible the P.A. System speakers can be placed on stage deck risers on either side of the main stage area. We include 2 such decks in our standard package, each 1M X 2M, on 3 feet legs (with jackscrews for levelling).

Alternatively for a small additional cost we can supply a full stage height P.A Goalposts to each side of the stage. Additional risers are available including a drum riser for a small extra cost.

Access Steps / Ramp

These are two sets of these, made of non-slip aluminium and with safety handrails both sides.

Equipment ramps are also available as an extra, as is a a fully compliant Disabled Access Ramp.

Branding Banner sizes, 10 x 6 stage

As a rule we have found that the following sizes are best for branding:

1. Front skirt 900mm high, 10m long. Velcro loop along the top.

2. Stage rear banners should be ideally 8m wide and 4m top to bottom. Deeper than this and no-one will see the banner’s bottom part for Artistes and equipment. Eyelets across the top and sides - please provide cable ties and cord.

3. Vertical banners on the front truss roof supports are best about 2m wide and 4m top to bottom; again, eyelets (three at the top and bottom corners and central at the top and bottom) give us hanging options.

This is only a guide and we are happy to help with branding queries.

Lighting:

Stage lighting including theatrical lighting with par cans, moving heads and LED lighting effects are available from our large stock – please ask us for a quotation.

Sound:

We can provide P.A Systems to cover music events up to 6000. From a single microphone right up to full concerts with multiple bands. Please get in touch to discuss your requirements.

Wind Loading:

The maximum gusting wind loading for the freestanding stage is 70 kph; above this, additional guy straps are required with ground anchorage. Additionally, solid back and side covers can be changed to scrim material which allows air to pass through.

Safety Earth Bond:

We provide a heavy duty stage earth bond as standard.

Fire Extinguishers and first aid:

We supply two x CO2 2kg. fire extinguishers with the stage. These are certified as conforming to BS5306 Part 3 and annually tested. We also carry a general purpose first aid kit.
